Large Cold Rooms For Logistics Warehouse
>

Large Cold Rooms For Logistics Warehouse

Large Cold Rooms For Logistics Warehouse

High degree of automation. The system is controlled by microcomputer, and the temperature of small cold storage can be adjusted arbitrarily in the range of - 10 ~ 15 ℃. It can automatically control the temperature, and the temperature control is accurate, and the temperature difference is ≤± 0.5 ℃.

Panel connection adopts eccentric locking type, with good air tightness, good sealing, good heat preservation effect, convenient disassembly, flexible movement and so on. Cold storage can be assembled in different places in different sizes and capacities.

Brand: MGREENBELT
Product origin: China
Delivery time: 30 days after advance payment

Information
Video

Large Cold Rooms For Logistics Warehouse

cold rooms

Cold Room introduction:

Whether you are looking for cold rooms, refrigeration condensing units, insulation panels, evaporator air coolers, MGREENBELT is the go- to professional manufacturer.

Mgreenbelt cold rooms, typical temperature range of -30°C to +10°C . It can store frozen meat, fish, seafood, chicken, ice cream, vegetables, fruits, dairy products, beverages etc. Cold room is staples of logistics warehouse, restaurants, farms, hotels, supermarkets facilities.

Panel connection adopts eccentric locking type, with good air tightness, good sealing, good heat preservation effect, convenient disassembly, flexible movement and so on. Cold storage can be assembled in different places in different sizes and capacities.

Features:

1. Nice appearance :The insulation panel and framework are available in dozens of colors which are to be elected in satisfactory harmony with various styles of buildings.

2. Insulation : Polyurethane or polystyrene with low thermal conductivity and high strength is utilized, achieving good insulation performance.

3. There are Condensing Unit and Unit Cooler refrigeration devices. Different models of temperatures can be selected according to different cold storage.

4. Fast installation.

5. Hygienic conditions of food inside cold stores are up to the standards.

6. Durable building structure, super quality material.

Specifications details:

Model			MGH-M
Model			MG02H-M	MG03H-M	MG04H-M	MG05H-M	MG06H-M	MG07H-M	MG09H-M	MG10H-M	MG12H-M	MG15H-M	MG20H-M
Compressor model		Old	2GC2.2Y	2EC3.2Y	2CC4.2Y	4FC5.2Y	4EC6.2Y	4DC7.2Y	4CC9.2Y	4VCS10.2Y	4TCS12.2Y	4PCS15.2Y	4NCS20.2Y
Compressor model		New	2GES-2Y	2EES-3Y	2CES-4Y	4FES-5Y	4EES-6Y	4DES-7Y	4CES-9Y	4VES-10Y	4TES-12Y	4PES-15Y	4NES-20Y
Cooling capacity/ power	Evaporating -5℃	Cooling capacity(kW)	4.61	7.38	10.88	11.8	14.82	17.35	21.6	22.7	27.4	31.3	37.4
	Evaporating -5℃	Power (kW)	1.88	2.66	3.94	4.24	5.36	6.21	7.85	7.77	9.54	10.85	12.89
	Evaporating -10℃	Cooling capacity(kW)	3.78	6.05	8.97	9.67	12.12	14.21	17.7	18.35	22.3	25.3	30.4
	Evaporating -10℃	Power (kW)	1.75	2.47	3.66	3.97	5.0	5.8	7.29	7.14	8.78	9.93	11.87
Applicable temperature(℃)			-5~5
Refrigerant			R404A
Power supply			380V/3P/50Hz
Condenser	Fan quantity		1	2	2	2	2	2	2	2	4	4	4
	Fan voltage(V)		380	380	380	380	380	380	380	380	380	380	380
	Fan power(W)		180×1	180×2	180×2	180×2	180×2	250×2	250×2	250x2	180x4	180×4	180×4
Coupling	Suction coupling(mm)		φ16	φ22	φ22	φ22	φ28	φ28	φ28	φ28	φ35	φ35	φ42
Coupling	Tube coupling(mm)		φ10	φ12	φ12	φ12	φ12	φ16	φ16	φ16	φ16	φ22	φ22
Overall dimensions		L(mm)	620	960	1060	1300	1300	1300	1280	1280	1280	1280	1350
		W(mm)	650	680	680	750	750	750	710	710	710	750	800
		H(mm)	560	460	720	670	770	870	910	910	1210	1460	1410
Mounting dimensions(LxW) (mm)			580×350	920x380	920×380	1260x410	1260x410	1260x410	1000x665	1000x665	1000x665	1000×705	1000x755
