Supply Stainless Steel Fresh Fish Cold Storage Wholesale Factory

Stainless Steel Fresh Fish Cold Storage

The cold storage is mainly used for freezing, processing and refrigeration of food, medicine and machinery. It keeps the room at a certain low temperature through manual refrigeration. The wall, floor and flat roof of the cold storage building are covered with a certain thickness of thermal insulation materials to reduce the external heat transfer of the cold storage. In order to reduce the absorption of solar radiation, the external wall surface of the cold storage is generally painted white or light color. Therefore, the cold storage building is different from the general industrial and civil buildings, and it has its own unique structure.

Brand: MGREENBELT
Product origin: China
Delivery time: 30 days after advance payment

Information
Video

Stainless Steel Fish Cold Storage

Fish Cold Storage

Stainless Steel Cold Storage

Fish cold storage introduction:

Whether you are looking for fish cold storage, refrigeration condensing units, insulation panels, evaporator air coolers, MGREENBELT is the go- to professional manufacturer.

Mgreenbelt fish cold storage, typical temperatures for our cold room range from of -30°C to -10°C. It can store frozen meat, fish, seafood, chicken, ice cream etc. Fish cold storage is staples of logistics warehouse, restaurants, farms, hotels, supermarkets facilities.

Features of fish cold storage:

1. Nice appearance :The insulation panel and framework are available in dozens of colors which are to be elected in satisfactory harmony with various styles of buildings.

2. Insulation : Polyurethane or polystyrene with low thermal conductivity and high strength is utilized, achieving good insulation performance.

3. Fast installation.

4. Hygienic conditions of food inside cold stores are up to the standards.

5. Durable building structure, super quality material.

Specifications:

Model			MGH-M
Model			MG02H-M	MG03H-M	MG04H-M	MG05H-M	MG06H-M	MG07H-M	MG09H-M	MG10H-M	MG12H-M	MG15H-M	MG20H-M
Compressor model		Old	2GC2.2Y	2EC3.2Y	2CC4.2Y	4FC5.2Y	4EC6.2Y	4DC7.2Y	4CC9.2Y	4VCS10.2Y	4TCS12.2Y	4PCS15.2Y	4NCS20.2Y
Compressor model		New	2GES-2Y	2EES-3Y	2CES-4Y	4FES-5Y	4EES-6Y	4DES-7Y	4CES-9Y	4VES-10Y	4TES-12Y	4PES-15Y	4NES-20Y
Cooling capacity/ power	Evaporating -5℃	Cooling capacity(kW)	4.61	7.38	10.88	11.8	14.82	17.35	21.6	22.7	27.4	31.3	37.4
	Evaporating -5℃	Power (kW)	1.88	2.66	3.94	4.24	5.36	6.21	7.85	7.77	9.54	10.85	12.89
	Evaporating -10℃	Cooling capacity(kW)	3.78	6.05	8.97	9.67	12.12	14.21	17.7	18.35	22.3	25.3	30.4
	Evaporating -10℃	Power (kW)	1.75	2.47	3.66	3.97	5.0	5.8	7.29	7.14	8.78	9.93	11.87
Applicable temperature(℃)			-5~5
Refrigerant			R404A
Power supply			380V/3P/50Hz
Condenser	Fan quantity		1	2	2	2	2	2	2	2	4	4	4
	Fan voltage(V)		380	380	380	380	380	380	380	380	380	380	380
	Fan power(W)		180×1	180×2	180×2	180×2	180×2	250×2	250×2	250x2	180x4	180×4	180×4
Coupling	Suction coupling(mm)		φ16	φ22	φ22	φ22	φ28	φ28	φ28	φ28	φ35	φ35	φ42
Coupling	Tube coupling(mm)		φ10	φ12	φ12	φ12	φ12	φ16	φ16	φ16	φ16	φ22	φ22
Overall dimensions		L(mm)	620	960	1060	1300	1300	1300	1280	1280	1280	1280	1350
		W(mm)	650	680	680	750	750	750	710	710	710	750	800
		H(mm)	560	460	720	670	770	870	910	910	1210	1460	1410
Mounting dimensions(LxW) (mm)			580×350	920x380	920×380	1260x410	1260x410	1260x410	1000x665	1000x665	1000x665	1000×705	1000x755
